Federally Approved | ADR-Tested | SSM Certified
RAM 2500 6th Gen GVM Upgrades Australia
Federally approved GVM upgrade packages for the RAM 2500 6th Gen. Every stage is ADR-tested, SSM-certified, and installed by our national network of approved specialists.
- Federal / SSM Certification
- ADR-Tested & Approved
- Australia-Wide Installer Network
Why Upgrade Your RAM 2500 6th Gen's GVM?
ORI RAM 2500 6th Gen GVM & GCM Specifications
OEM
Stage 1
Stage 2
Stage 3
Stage 4
Stage 5
Stage 6
Gross Vehicle Mass (GVM)
4495 KG NB1
5500 KG
5890 KG
5890 KG
5890 KG
5890 KG
5800 KG
Braked Towing Capacity (BTC)
4500 KG
4500 KG
4500 KG
4500 KG
4500 KG
4500 KG
4500 KG
Gross Combined Mass (GCM)
12,750 KG
12,750 KG
12,750 KG
12,750 KG
12,750 KG
12,750 KG
12,750 KG
Kerb Weight
3710 KG
3760 KG
3770 KG
3830 KG
3830 KG
3830 KG
3830 KG
Payload (based on kerb weight)
886 KG
1740 KG
2120 KG
2060 KG
2060 KG
2060 KG
2060 KG
Front Axle Capacity
2722 KG
2722 KG
2722 KG
2722 KG
2722 KG
2722 KG
2722 KG
Rear Axle Capacity
2740 KG
3175 KG
3175 KG
3175 KG
3175 KG
3175 KG
3075 KG
Wheel Offsets
POS 47
Pos 18
Pos 18
Pos 18
Pos 18
Pos 18
Pos 12 | Zero | -11
Wheel Load Rating
1587 KG
1600 KG
1600 KG
1600 KG
1600 KG
1600 KG
1600 KG
Minimum Tyre Load Rating
124 Q
124 Q
124 Q
124 Q
124 Q
124 Q
Requires Wheel/ Tyre Upgrade
OEM
✓
✓
✓
✓
✓
✓
Maximum Tyre Size
35x12.5xR18
35x12.5xR20
35x12.5xR20
35x12.5xR18
35x12.5xR20
35x12.5xR20
37x12.5xR18
37x12.5xR20
37x12.5xR20
37x12.5xR18
37x12.5xR20
37x12.5xR20
37x12.5xR18
37x12.5xR20
37x12.5xR20
40x13.5R17 | 40x13.5R18 | 40x13.5R20
Frequently Asked Questions
What is a GVM upgrade?
A GVM (Gross Vehicle Mass) upgrade increases the maximum legal weight your vehicle can carry, using SSM certification.
How much payload can I legally gain?
Gains vary by vehicle and stage. Contact us for figures specific to your RAM 2500 6th Gen.
What is the difference between the stages?
Each stage offers a different GVM and suspension package. See the package grid above.
